- POE Power Input !
- ARM Cortex RK3288 !
- Android 5.1/9.0, Debian 9.0 !
- IP65 Front !
incl. 19% VAT, plus shipping
Available in 3-7 days
|Front Bezel||– IP65, NEMA 4 rugged protection, metal front bezel|
|Display Type||– 10.1″ With LED Backlight|
|Brightness (cd/m²)||– 350 nits|
|Display Color||– 262K|
|Resolution||– 1280 x 800 @ 60Hz resolution|
|Viewing Angle (H/V)||– 160°/160°|
|Pixel Pitch||– 0.1695 x 0.1695mm|
|Aspect Ratio||– 16:10|
|Contrast Ratio||– 600:1|
|Response Time||– 25 ms|
|Type||– Projected capacitive type|
|Active Range||– 257.10 x 159.66mm ±0.2mm|
|Transparency||– ≧ 87%|
|Surface Hardness||– ≧ 6H (ASTM D3363, pressure 1N/45°)|
|Operating Force||– ≦ 80g|
|Panel Material||– Aluminum|
|Case Material||– Iron|
|Coating Requirement||– Spray Paint|
|CPU||– Rockchip® ARM Cortex A17 1.8GHz/QC processor|
|RAM||– Onboard 1333/2GB DDR3L DRAM|
|Flash ROM||– Onboard 8G Flash ROM|
|Watchdog Timer||– 256 levels, 0~255 sec.|
|Speaker||– 2* 2W/8Ohm|
|Camera||– 1* 500W USB (Option)|
|OS Support||– Android 5.1/9.0 or Debian 9.0|
|Expansion||– 1* Micro SD socket|
|Regulatory Compliance||– N/A||– IEEE802.3af (PoE)|
|Input Power||– N/A||– 44~57V input|
|Pass Through Data Rates||– N/A||– 10/100/1000 Mbps|
|Power Consumption||– N/A||– 8.5W|
– 2* USB2.0 (USB1 Co-lay OTG)
– 1* HDMI 1.4
– 1* AUDIO(Line-out +MIC)
– 1* Micro SD Socket
– 1* Power Button
– 1* RJ45
– 1* DC jack
|– 1* PoE PD|
|Power Input||– 12V DC-in||– 44~57V input|
|Power Consumption||– 8.5W|
|Case Dimensions||– 259.3 * 177.3 * 39.0mm|
|Compliance||– CE, FCC, IP65(Front)-Option|
– Operating Temperature: -10 ~ 50° C
– Storage Temperature: -20 ~ 60° C
|Shock||– 15G, 11ms duration|
|Vibration||– 5~500Hz/1 Grms|
