POE Gigabit Switch (4x POE IEEE802.3af/at, 1x LAN, 1x SFP, 60W)

PRODUCT IS CURRENTLY NOT AVAILABLE !
POE Gigabit Switch (4x POE IEEE802.3af/at, 1x LAN, 1x SFP, 60W)

6-Port Gigabit Switch with 4-Port PoE provides the seamless network connection. It integrates 1000Mbps Gigabit Ethernet and 10/100Mbps Fast Ethernet network capabilities.

6 Auto-Negotiation RJ45 ports (port-1 to port-4) of the switch support Power over Ethernet (PoE) function. These PoE ports can automatically detect and supply power with those IEEE 802.3af compliant Powered Devices (PDs). In this situation, the electrical power is transmitted along with data in one single cable allowing you to expand your network where there are no power lines or outlets, where you wish to fix devices such as APs, IP Cameras or IP Phones, etc.

Easy To Use
Easy to
[more]

Share

999.00 EUR
incl. 19% VAT, plus shipping
Product currently unavailable. We check availability again when ordering.

Add to cart

6-Port Gigabit Switch with 4-Port PoE provides the seamless network connection. It integrates 1000Mbps Gigabit Ethernet and 10/100Mbps Fast Ethernet network capabilities.

6 Auto-Negotiation RJ45 ports (port-1 to port-4) of the switch support Power over Ethernet (PoE) function. These PoE ports can automatically detect and supply power with those IEEE 802.3af compliant Powered Devices (PDs). In this situation, the electrical power is transmitted along with data in one single cable allowing you to expand your network where there are no power lines or outlets, where you wish to fix devices such as APs, IP Cameras or IP Phones, etc.

Easy To Use
Easy to install and use. It requires no configuration and installation. With desktop design, outstanding performance and quality, the 6-Port Gigabit Desktop Switch with 4-Port PoE is a great selection for expanding your home or office network.

Key Features:
* Supports PoE power up to 15.4W for each PoE port
* Supports PoE power up to 60W for all PoE ports
* Supports PoE IEEE 802.3af compliant PDs
* Supports IEEE 802.3x flow control for Full-duplex Mode and backpressure for Half-duplex Mode
* 4 ports with poe, 1 port 10/100/1000M RJ45 and 1Port Gigabit SFP
* External power adapter (60W[48V/1.25A])

Interface 5 10/100/1000Mbps RJ45 Ports 1 10/100/1000Mbps SFP Solt
AUTO Negotiation/AUTO MDI/MDIX
Network Media 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m) EIA/TIA-568 100Ω STP (maximum 100m)
Fan Quantity Fanless
External Power Supply External Power Adapter(Output: 48VDC /1.25A)
PoE Ports (RJ45) Standard: 802.3 af/at compliant
PoE Ports: Port1- Port 4
Power Supply: 60W
Backbound Bandwidth 10Gbps
Mac Address Table 4K
Dimensions ( W x D x H ) (160*90*28 mm)
Transmission Method Store-And-Forward
Advanced Functions Compatible With IEEE 802.3af Compliant PDs
Priority Function
Mac Address Auto-Learning And Auto-Aging
EEE802.3x Flow Control
802.1p/DSCP QoS
Certification CE, FCC, RoHS
Package Contents Switch, Power Adapter
Environment Operating Temperature: 0°C~40°C Storage Temperature: -40°C~70°C
Operating Humidity: 10% ~ 90% non-condensing
Storage Humidity: 5%~90% non-condensing
Data sheet Download (PDF)
Data sheet Print view
Please login for creating product ratings.
Your rating:

Please tell us your opinion. Rate the product on a scale from 1 to 5. A value of 5 means the best possible rating. If you want you also can leave a comment.

Your ratings are honored on many ways. Your report will help other customers to better judge about the products. And you can benefit from reports other customers are giving.

In addition we credit 0.50 EUR for each given rating with comment and 1.00 EUR for each given rating with comment (more than 150 characters) on your account. The credit will be substracted automatically on your next order !

We reserve us the right to delete given comments (for example on attempts to give comments with senseless content, copying of other comments, inserting of foreign content, abusing the system for financing orders). "Fair-use-policy" does apply (as of rule of thumb you should give comments for products which you have purchased already. And your credit account only in rare cases will have 2 or even 3 digits). The credit can only be withdrawn by placing an order. It is not possible to get the credit cash or transferred in an other way.

Gigabit Switch
Switch at device:
N: Standard Normal All ports communicate freely, adapting to common data transmission environment
V: Port Isolation Switch to VLAN mode;downlink isolating from each other,uploads and
downloads data through uplink; suppress network failure like broadcast storm and virus attack
S: Ultral-far Mode Downlink speed limitation:10M(Ultral-far transmission:250 meters)
