M300-LCD Enclosure (1x PCI)

PRODUCT IS CURRENTLY NOT AVAILABLE !
M300-LCD Enclosure (1x PCI)
3D 360° View
  • Tiny size !!!
  • For PicoPSU !
  • Bootable CF-Reader
  • 1x PCI Slot !

- Up to two 2.5" drives
- Intelligent USB display with 20 columns and 2 rows and 8x5 dots character size included
- Allows PCI card (riser included)
- Bootable (IDE) Compact-Flash
- PWR button and LED
- Works with any picoPSU (not included)
- Size 20cm (w) x 7.8 cm x 24cm


The M300-LCD-Enclosure is a versatile mini-ITX enclsosure designed for embedded applications where CDROM drives are not required. The M300-LCD-Enclosure fits any type of mini-ITX board with standard back I/O shield. Not recommanded for EPIA 800, EPIA 5000 and EPIA CN series because of the different USB header pinout. The M300-LCD-Enclsoure will work with up to two IDE or SATA 2.5
[more]

Share

999.00 EUR
incl. 19% VAT, plus shipping
Product currently unavailable. We check availability again when ordering.

4 von 5 Sternen
11 ratings

Add to cart

- Up to two 2.5" drives
- Intelligent USB display with 20 columns and 2 rows and 8x5 dots character size included
- Allows PCI card (riser included)
- Bootable (IDE) Compact-Flash
- PWR button and LED
- Works with any picoPSU (not included)
- Size 20cm (w) x 7.8 cm x 24cm


The M300-LCD-Enclosure is a versatile mini-ITX enclsosure designed for embedded applications where CDROM drives are not required. The M300-LCD-Enclosure fits any type of mini-ITX board with standard back I/O shield. Not recommanded for EPIA 800, EPIA 5000 and EPIA CN series because of the different USB header pinout. The M300-LCD-Enclsoure will work with up to two IDE or SATA 2.5" disk drives (disk drive cable adapter not included).

The M300-LCD-Enclsosure is compatible with an entire range of DC-DC picoPSU power supplies, allowing system designers to pick the right PSU for their application (picoPSU not included in this assembly)

The M300-LCD-Enclosure has a front door for extra ESB ports and Bootable Compact Flash adapter (included in this assebly), making this enclosure perfect for systems that boot from flash (Compact Flash). The M300-LCD-Enclosure has all the features of the M200-Enclosure, however it allows the installation of a PCI card via PCI riser card (included in this assebly)

The M300-LCD-Enclosure comes in a white OEM box that can be re-branded. The enclosure has a small area for OEM logo, allowing system integrator to re-brand the unit, making this enclosure the perfect candidate for embedded applications.

Note :With Intel D945GCLF mainboard you can not use the LCD module because the USB connection cable is too short.

Data sheet Download (PDF)
Data sheet Print view
Please login for creating product ratings.
Your rating:

Please tell us your opinion. Rate the product on a scale from 1 to 5. A value of 5 means the best possible rating. If you want you also can leave a comment.

Your ratings are honored on many ways. Your report will help other customers to better judge about the products. And you can benefit from reports other customers are giving.

In addition we credit 0.50 EUR for each given rating with comment and 1.00 EUR for each given rating with comment (more than 150 characters) on your account. The credit will be substracted automatically on your next order !

We reserve us the right to delete given comments (for example on attempts to give comments with senseless content, copying of other comments, inserting of foreign content, abusing the system for financing orders). "Fair-use-policy" does apply (as of rule of thumb you should give comments for products which you have purchased already. And your credit account only in rare cases will have 2 or even 3 digits). The credit can only be withdrawn by placing an order. It is not possible to get the credit cash or transferred in an other way.

Customer ratings: 4 von 5 Sternen
Average rating, based on 11 ratings
5 von 5 Sternen from bausano am 17.01.2013 | | See all my comments
3 von 5 Sternen from ureinkauf am 11.04.2012 | | See all my comments

nur 3 Sterne,
Gerät ok,etwas teuer,aber mit dem LCD & CR viel Hardware,
leider kein NT dabei & Blech etwas dünn bemessen,
optisch ok,leider keine SW für LCD,
insgesamt ok

3 von 5 Sternen from daggett29 am 12.12.2010 | | See all my comments

Bis jetzt gab es ein paar Probleme kein Anschlusskabel lag bei beim CF Cardreader. Beim LCD-Display lag auch keine Software bei mit dem man es irgendwie für andere Zwecke verbinden kann. Ich suche seit 1 Woche bei Google hab aber nur die Orginal Software gefunden mit der man ein wenig Testen kann. für Winamp liegt ein Plugin bereit. das Funktioniert ohne Probleme. Wenn es noch eine Software für win XP Sp2 gibt mit der man Computer spezifische meldungen ausgeben kann, würde ich mich über eine Nachricht freuen.
Ansonsten ist das Gehäuse super in der Abmessung und schön Gebaut.

2 von 5 Sternen from kinglyr am 27.01.2010 | | See all my comments

you sell it too expensive.
In US it costs $109.95, which is 109.95/1.4=EUR78.53

approximately twice the price of one!
And do not tell me that it is due to customs :-)

Update from :2010-02-11 22:52
It is the best enclosure you can buy worldwide in order install the INTEL D945GCLF or GCLF2 mobos. However, there are some issues about this box. First of all there is no much space inside to install HDDs. Second the price offered is too expensive compared with the price that has at the US market.

5 von 5 Sternen from niklas.sandler@helsinki.fi am 27.08.2009 | | See all my comments

Excellent compact choice of enclosure for our purposes!
