Jetway JNF694-3350/4200 (Intel Apollo Lake)

• Intel® Apollo Lake SoC Processor
• 1/2 * DDR3L SODIMM Up to 8 GB
• 1/2 * 10/100/1000 Base-TX Ethernet Ports
• Support 1 * HDMI + 1 * DP display
• 4/6 * COM, 4 * USB3.0 & 2 * USB2.0
• 1 * PCIe x1 slot, 1* Mini PCIe slot (1* full size), 1 * M.2 (M-key, 2242/2260)
• Support 1 * SATA III (6Gb/s)
• 24-pin ATX PWR

• Intel® Apollo Lake Processor
• 1 * DDR3L 1866MHz SODIMM Up to 8GB
• 1/2* 10/100/1000 Base-TX Ethernet Ports
• Support HDMI / VGA / LVDS / eDP display selection
• 2/6/10 * COM, 4 * USB3.0 & 6 * USB2.0
• 1* Mini PCIe slot & 1 * SIM card holder
• Support 1 * SATA III (6Gb/s) & 1 * M.2 (M-key, 2242/2260)
• 12V DC-in power

• Support Intel Celeron mobile processor 3855U (FCBGA1356)
• TWO 260-pin SO-DIMM up to 32GB DDR4 2133MHz SDRAM
• Supports 1* DVI-D, 1* HDMI, 1* DP (option)
• Supports 1* PCIe x4 and 1* Mini PCIe
• Supports 4* USB3.0, 3* USB2.0
• Mini ITX Form Factor

• Intel® Skylake-3855U SoC
• Support DDR4/2133
• 2 * PCI Express Gigabit LAN
• Support Power Onboard(12V)
• Onboard 1 * Mini PCI-E connector, 1 * M.2 (2242/2260) connector for SSD
• Mini-ITX Form Factor (170mm * 170mm)

• Intel® Bay Trail-D J1900 SOC (CO-LAY N2930)
• Onboard INTEL® J1900 2.0GHz Quad Cores CPU
• Support 1* DDR3/1333 SO-DIMM Max 8GB
• 1* GbE, 1* USB3.0, 8* USB2.0, 4* COM (COM1/2 Support 5V/12V)
• Support 1 * SIM Card(Option)
• Support CRT+ EDP+LVDS Display(Co-lay CRT +2*EDP)
• Thin Mini-ITX Form Factor(170 x170mm)

• Support DDR3 /DDR3L 1600/1333 up to 16GB
• 4 * USB3.0 (PCI-E to USB3.0), 8 * USB2.0, 2 * GbE
• 12 * RS232(COM1/COM2 support RS232/422/485, COM3/COM4 support RS232/485)
• 2 * CRT Ports (CRT2 support Dummy load function)
• SIM Card Socket, TPM Header
• 4 Phase CPU Power Support 84W CPU

• Intel Apollo Lake processor (10W)
• 1 * SO-DIMM DDR3L up to 8GB
• 4 * USB3.0, 1 * COM, 1 * VGA, 2 * HDMI, 2 * RJ45, 1 * Audio (Mic + Line-out)
• M/B Form Factor :NUC (101x101mm)
• DC-12V_40W Adapter

• Intel® Apollo Lake N3350/N4200 SoC Processor
• Support 1 * DDR3L 1866MHz SO-DIMM up to 8GB
• 2 * USB3.0 ,1 * GbE LAN ,1 * HDMI , 1 * Micro SIM
• Support M.2 (M-key, SATA interface, 2242) storage
• M/B Form Factor : PICO SBC (100x72mm)
• DC-12V_40W Adapter

• Intel® LGA1151 Socket Core i3,i5,i7 & Pentium Processors(max.65W)
• Support DDR4-2133Mhz, 2 * SO-DIMM slot, up to 32GB memory
• 2 * USB2.0, 4 * USB3.0, 1 * HDM , 1 * DP, 2 * RJ45, 1 * MIC, 1 * Line in, 1 * Line out
• M/B Form Factor : Mini ITX (170x170mm)
• 1U 200W FLEX Power

• Intel® Skylake/Kabylake U-series Processor (Default Celeron 3965U)
• 2 * 260-pin Dual-channel DDR4 2133MHz SO-DIMM Up to 32 GB
• 2 * USB2.0, 6 * USB3.0, 1 * COM, 1 * DP, 1 * HDMI, 2 * RJ45,1 * Line-in, 1 * MIC+Line-out Combo
• M/B Form Factor : uTX (117x112mm)
• DC-12V_40W Adapter

• Intel® Skylake/Kabylake U-series Processor (Default Celeron 3965U)
• 2 * 260-pin Dual-channel DDR4 2133MHz SO-DIMM Up to 32 GB
• 2 * USB2.0, 6 * USB3.0, 1 * COM, 1 * DP, 1 * HDMI, 2 * RJ45,1 * Line-in, 1 * MIC+Line-out Combo
• M/B Form Factor : uTX (117x112mm)
• DC-12V_40W Adapter

• Intel® Apollo Lake N3350/N4200 SoC Processor
• Support 1 * DDR3L 1866MHz SO-DIMM up to 8GB
• 1* GbE, 2* Internal COM ports, 2* External USB3.0 & 2* Internal USB2.0
• Support HDMI and LVDS
• Support M.2 (M-key, SATA interface, 2242) storage
• 1 * full size Mini-PCIe slot
• 12V DC-in power

• 2. Onboard INTEL® Braswell-M N3160 2.24GHz QC CPU
• Onboard SAMSUNG 2G 1600/1333MHz DDR3L Memory
• 1* GbE, 3* USB3.0, 2* COM, 1* HDMI, 1* eDP, 1* SIM card holder
• Support power onboard (9~24V)

• Onboard SAMSUNG 4G 1600/1333MHz DDR3L Memory
• Support 2*PCI Express Gigabit LAN
• Support 3*USB3.0 Ports, 2*COM ports
• Support SIM Card Socket
• Support 2*HDMI+1*DP
• Power onboard (wide voltage input :9~24V)

• Intel® Skylake/Kabylake U-series Processor (TDP 15W)
• 2 * 260-pin Dual-channel DDR4 2133MHz SODIMM Up to 32 GB
• 2 * 10/100/1000 Base-TX Ethernet Ports
• Support Intel AES NI and TPM (option) to secure customers data
• 8 * Ext USB3.0/2.0, Line-In/Line-Out/MIC, 1 * HDMI, 1 * DP or VGA
• 2* Mini PCIe Slots (1* full size & 1* half size), 1 * SIM card holder

• Intel® Apollo Lake SoC Processor
• 1 * 204-pin DDR3L 1866MHz SODIMM Up to 8 GB
• 2 * 10/100/1000 Base-TX Ethernet Ports
• Support Intel AES NI and TPM2.0 to secure customers data
• 4 * Ext USB3.0, 1 * Line-Out/MIC, 2 * HDMI, 1 * VGA
• 1* full size mSATA, 1* half size Mini PCIe Slot, 1 * SIM card holder
• 12V DC-in power

• Intel® Braswell Processor
• 1 * DDR3L 1600MHz SODIMM, up to 8GB
• Support HDMI, Display Port, LVDS Triple Independent Displays
• 2 * Intel i211AT GbE
• Integrated Realtek ALC662VD Audio CODEC with 6-CH
• 1 * Serial ATAIII (6Gb/s)
• 1 * External RS232(RJ45 Type) & 5 * Internal COM (COM2 support RS232/422/485)
• 4 * External USB3.0 & 2 * Internal USB1.1/2.0
• 1 * half size Mini PCIe, 1 * M.2 (M-key, 2242)
• +9V~+36V Lockable DC-in Jack
• 3.5” SBC Form Factor (148mm * 102mm)

• Intel® Celeron™ J1900 (2.0 GHz) quad-core processor
• Onboard SAMSUNG 4G/1333MHz DDR3L Memory
• Supports up to 2 Displays, LVDS,EDP, VGA
• 1 * M.2 Socket (2242/2260/2280)
• Dual Intel® Gigabit LAN
• 4 * Serial Ports (COM1/2 RS232/422/485), 8-bit GPIO, 2 * USB 3.0 Ports, 6 * USB 2.0 Ports, Watchdog Timer
• +9V ~ +28V DC-in or 4-pin Internal Power Connector
• 5.25” Form Factor (120mm * 200mm)

Jetway JNF699-C3758 (Intel Denverton)
The JETWAY JNF699-C3758 is Mini-ITX form factor board adopts the Intel® Denverton C3758 (8 Core, 2.20GHz, 25W TDP) SoC Processor. The board supports four DDR4 2133/2400MHz, 288-pin U-DIMM/R-DIMM slots, up to 64/128GB memory. Featuring the integrated Intel® Gigabit Ethernet controller, the JNF699-C3758 offers two 10/100/1000Base-TX Ethernet devices and four 10GbE SFP+ for network transmission. Four SATAIII (6Gb/s) interface and one M.2 (M-key, 2242/2260/2280) offer storage devices. One full size Mini PCIe interface, three USB3.0 ports, two USB2.0 ports and two COM ports provide versatile expansion. The PCIex8 (use x16 slot) can support Jetway riser card for different expansion. The JNF699-C3758 offers 2 * Intel GbE and 4 * 10GbE SFP+ which can support more networking appliance. Because of the above features, JNF699-C3758 is one of the best selections for Networking applications.



Jetway JNF699-C3758 (Intel Denverton)

Jetway HBJC160F699-3758-S (Intel Denverton)

• Intel® Denverton series Processor (TDP 15W)
• Support Registered ECC DDR4-2400MHz DIMM up to 128GB or Unbuffered ECC/Non-ECC DDR4-2400MHz DIMM up to 64GB
• 3 * USB3.0, 1 * VGA, 2 * RJ45, 4 * 10G SPF, 4 * Storage Drive, 4 * 2.5″ or 3.5″ Drive
• Support TPM (option)
• M/B Form Factor : Mini ITX (170x170mm)
• 1U 300W FLEX Power
